Vactor Sewer Cleaner Equipment

Equipment Specification Table

Model	2100i Fan	2100i PD	iMPACT	Ramjet Truck	Ramjet Trailer
Design	Exclusive Vactor Modul-Flex®	Exclusive Vactor Modul-Flex®	Exclusive Vactor Modul-Flex®	Exclusive Vactor Modul-Flex®
Air Mover	Single Stage Hydrostatic Fan	Roots / Dresser positive displacement	Roots / Dresser positive displacement
Vacuum Rating		15 in (457 mm) Hg	Up to 15 in (381 mm) Hg
Inlet Volume		3500 CFM	Up to 2,400 CFM
Drive	Chassis driven, hydrostatic drive	Chassis driven, direct drive	Chassis driven, hydrostatic drive	Chassis driven, hydrostatic drive	Auxiliary engine 4 cylinder
Drive Components	Transfer Case and PTO	Transfer Case and PTO	PTO	PTO
Fully Hydraulic Boom	Proportional Boom Controls with 180º rotation	Proportional Boom Controls with 180º rotation	Proportional Boom Controls with 180º rotation
Pickup Hose	8" Diameter	8" Diameter	6 in (152 mm) Diameter
Debris Body Capacity	5 yd3 (3.8 m3)	5 yd3 (3.8 m3)	3 yd3 (2.3 m3)
Water Tank Capacity	1,000 gal (3,785 L)	1,000 gal (3,785 L)	500 gal (1,893 L)	1500 gal - 3000 gal (5678 L - 11356 L)	Up to 750 gal (2,839 L)
Water Tank Construction	Aluminum (10-year warranty)	Aluminum (10-year warranty)	Aluminum (10-year warranty)	Stainless steel
Water Pump	Vactor Jet Rodder® Multi-Flow system	Vactor Jet Rodder® Multi-Flow system	Vactor Jet Rodder® Multi-Flow system	Vactor Jet Rodder® Multi-Flow system	Tri-Plex Piston Pump
Water Delivery	60 gpm at 2,000 psi	60 gpm at 2,000 psi	40 GPM at 2500 psi	60 gpm at 2,000 psi	Up to 40 gpm at 3,000 psi
Pump Action	Continuous flow or Jack Hammer®	Continuous flow or Jack Hammer®	Continuous flow or Jack Hammer®
Hose Reel	15" Telescope, 270º rotation 800 ft x 1 in capacity (244 m x 2.5 cm)	15" Telescope, 270º rotation 800 ft x 1 in capacity (244 m x 2.5 cm)	180º rotation 500 ft x 3/4 in (152 m x 19 mm)	Front Mounted \| 800 ft x 1 in (244 m) Rear Mounted \| 700ft x 1 in (214 m)	Rear Mounted \| 600 ft x 3/4 in (183 m)
Rear Door	Flat, hydraulically opening with fail safe locks	Flat, hydraulically opening with fail safe locks	Flat, hydraulically opening with fail safe locks
Smart Truck Features	E-stops at all operator stations Flow / footage meters Smart messages	E-stops at all operator stations Flow / footage meters Smart messages	E-stops at all operator stations Flow / footage meters Smart messages	E-stops at all operator stations Flow / footage meters Smart messages
Hand Gun Systems	35' of hose High Pressure Washdown gun	35' of hose High Pressure Washdown gun	35' of hose High Pressure Washdown gun	35' of hose High Pressure Washdown gun	25' x 1/2'

Custom	2100i Fan	2100i PD	iMPACT	Ramjet Truck	Ramjet Trailer
Air Mover	Dual Stage Hydrostatic Fan	Roots / Dresser positive displacement	Roots / Dresser positive displacement
Vacuum Rating		16 & 18 in (457 mm) Hg	Up to 15 in (381 mm) Hg
Inlet Volume		4500 & 5000 CFM	Up to 2,400 CFM
Pickup Hose	7" or 8" Diameter	7" or 8" Diameter
Debris Body Capacity	5 yd³ - 15 yd³ (3.8 m³ - 11.5 m³)	5 yd³ - 15 yd³ (3.8 m³ - 11.5 m³)	5 yd³ (3.8 m³)
Water Tank Capacity	1,300 gal - 1,500 gal (4,921 L - 5,678 L)	1,300 gal - 1,500 gal (4,921 L - 5,678 L)	750 gal (2,840 L)	1500 gal - 3000 gal (5678 L - 11356 L)	Up to 750 gal (2,839 L)
Water Tank Construction	Stainless Steel (10-year warranty)	Stainless Steel (10-year warranty)	Stainless Steel (10-year warranty)	Stainless steel
Water Pump	Vactor Jet Rodder® Multi-Flow system	Vactor Jet Rodder® Multi-Flow system	Vactor Jet Rodder® Multi-Flow system	Vactor Jet Rodder® Multi-Flow system
Water Delivery	70 gpm - 120 gpm at 2,000 psi - 3000 psi	70 gpm - 120 gpm at 2,000 psi - 3000 psi	35 GPM at 3000 PSI	50 gpm - 100 gpm at 2000 psi - 3000 psi	Up to 40 gpm at 3,000 psi
Pump Action	Continuous flow or Jack Hammer®	Continuous flow or Jack Hammer®	Continuous flow or Jack Hammer®
Hose Reel	15" Telescope, 270º rotation 1000 ft x 1 in capacity (305 m x 2.5 cm)	15" Telescope, 270º rotation 1000 ft x 1 in capacity (305 m x 2.5 cm)		Front Mounted \| 1000 ft x 1 in (305 m) Rear Mounted \| 900ft x 1in (275 m)	Rear Mounted \| 600 ft x 3/4 in (183 m)
Hose Reel	Up to 1,000 ft capacity (305 m)	Up to 1,000 ft capacity (305 m)		Shroud - Rear hose reel available
Rear Door	Flat, hydraulically opening with fail safe locks	Flat, hydraulically opening with fail safe locks	Flat, hydraulically opening with fail safe locks
Smart Truck Features	E-stops at all operator stations Flow / footage meters Smart messages	E-stops at all operator stations Flow / footage meters Smart messages	E-stops at all operator stations Flow / footage meters Smart messages	E-stops at all operator stations Flow / footage meters Smart messages
Multiple Boom Options	RDB 1015 10’ Extendable Boom 10’ Tele Boom 5x5 Boom	RDB 1015 10’ Extendable Boom 10’ Tele Boom 5x5 Boom
Axles	Single or Tandem Tri-Drive and Drop axles also available	Single or Tandem Tri-Drive and Drop axles also available	Single	Single or Tandem Tri-Drive and Drop axles also available
Controls	Wireless Bellypack Handheld Wireless Corded Pendant	Wireless Bellypack Handheld Wireless Corded Pendant	Wireless Bellypack Handheld Wireless Corded Pendant	Wireless Bellypack Handheld Wireless
Water Recycling System	No	Yes
